price inc gst $A 6745.00
BOSE SM10Mid-HF Module of ShowMatch Linearray
- 2x 8" SM8 neodymium LF drivers
- 4x 2" voicecoil EMB25 neodymium HF drivers
- Frequency response 70Hz~17kHz ±3db
- Nominal dispersion 100°x10°
- Sensitivity LF 94db@1m HF 105db@1m
- Power capacity HF 100w RMS 400w peak
- Power capacity LF 450w RMS 1800w peak
- Maximum SPL HF 126db@1m RMS 132db@1m peak
- Maximum SPL LF 121db@1m RMS 127db@1m peak
- Dimensions WxHxD 793x282x465mm
- Weight 29.7kg
data sheet
user manual
website
price inc gst $A 6745.00
BOSE SM20Mid-HF Module of ShowMatch Linearray
- 2x 8" LF SM8 neodymium drivers
- 4x 2" voicecoil EMB25 neodymium HF drivers
- Frequency response 70Hz~17kHz ±3db
- Nominal dispersion 100°x20°
- Sensitivity LF 94db@1m HF 105db@1m
- Power capacity HF 100w RMS 400w peak
- Power capacity LF 450w RMS 1800w peak
- Maximum SPL HF 125db@1m RMS 131db@1m peak
- Maximum SPL LF 121db@1m RMS 127db@1m peak
- Dimensions WxHxD 793x303x467mm
- Weight 29kg
data sheet
user manual
website
price inc gst $A 6469.00
Bose PM8500N8ch Power Amplifier
- Flexible summing technology configurable for bridge or paralel modes
- 8x balanced inputs with onboard DSP with crossover, parametric EQ, filters, alignment delay and peak & RMS limiting
- Power output:
- 8x 300w@8Ω
- 8x 500w@4Ω
- 8x 450w@2Ω
- 4x 1000w@8Ω bridged
- Variable speed cooling fans
- Dimensions WxHxD 483x88x525mm
- Weight 12.8kg
data sheet
user manual
website
price inc gst $A 5989.00
Bose SMS118Bass Module of ShowMatch Linearray
- 18" LF18 neodymium LF driver
- Frequency response 32Hz~250Hz ±3db
- Sensitivity 94dB/1m
- Power capacity 750w RMS 3000w peak
- Maximum SPL 121dB@1m RMS 127dB@1m peak
- Dimensions WxHxD 765x540x775mm
- Weight 62kg
data sheet
user manual
website
price inc gst $A 5539.00
Bose PM8250N8ch Power Amplifier
- Power capacity 8x250w@4Ω per channel
- 8 balanced inputs
- Ethernet control and monitoring
- Software configurable to bridge or paralel modes
- Software matrix mixer with high & low pass filters, EQ & limiting on each channel
- Variable speed cooling fans
- Dimensions WxDxH 483x525x88mm
- Weight 12.8kg
data sheet
user manual
website
price inc gst $A 4849.00
Bose PM4500N4ch Power Amplifier
- Power capacity 4x500w@4Ω per channel
- 4 balanced inputs
- Ethernet control and monitoring
- Software configurable to bridge or paralel modes
- Software matrix mixer with high & low pass filters, EQ & limiting on each channel
- Variable speed cooling fans
- Dimensions WxDxH 483x525x88mm
- Weight 11.1kg
data sheet
user manual
website
price inc gst $A 4749.00
Bose MSA12X-BSteerable Line Array Loudspeaker
- 12x2¼" drivers in line array
- Balanced analog & Dante input connectors
- Vertical beam steering ±20°
- Frequency response 75Hz~17kHz ±3db
- Dispersion 160°x30°
- Vertical beam steering ±20°
- Sensitivity 90db@1m @1w/1m
- Maximum SPL 112db@1m
- Power rating 150w RMS 600w peak
- Dimensions WxHxD 106x984x206mm
- Weight 14.5kg
data sheet
design guide
user manual
price inc gst $A 4749.00
Bose MSA12X-WSteerable Line Array Loudspeaker
- 12x2¼" drivers in line array
- Balanced analog & Dante input connectors
- Vertical beam steering ±20°
- Frequency response 75Hz~17kHz ±3db
- Dispersion 160°x30°
- Vertical beam steering ±20°
- Sensitivity 90db@1m @1w/1m
- Maximum SPL 112db@1m
- Power rating 150w RMS 600w peak
- Dimensions WxHxD 106x984x206mm
- Weight 14.5kg
data sheet
design guide
user manual
price inc gst $A 4365.00
Bose L1 PRO32-SUB2
Biamp Array Loudspeaker
Biamp Array Loudspeaker
- 32x 2" neodymium drivers in straight line array
- 1x Bose SUB2 Powered bass module with 10x18" neodymium oval driver
- Power capacity HF 480w & LF 1000w
- LF frequency response 37Hz
- Dispersion 180°H;x0°V
- Maximum SPL continuous 122db@1m peak 128db@1m
- 2ch input with independent volume control
- Digital ethercon port for T4S or T8S ToneMatch audio engines
- Column & stand dimensions WxHxD 345x2135x550mm
- SUB2 bass module dimensions WxHxD 305x690x550mm
- Combined weight 37.4kg
data sheet
user manual
video clip
website
price inc gst $A 4312.00
BOSE AMM112Coaxial Loudspeaker
- 12" LF driver & 3" HF compression driver
- Frequency response 70Hz~18kHz ±3db
- Dispersion 110°x60°
- Sensitivity 96db @1w/1m
- Power capacity 300w RMS 2800w peak
- Maximum SPL 121db@1m RMS 131db@1m peak
- Outdoor rating IP43
- Dimensions WxHxD 477x477x383mm
- Weight 22.04kg
data sheet
user manual
website
price inc gst $A 3919.00
Bose P4150+4ch Amplifier
- Power capacity 150ww each of 4 channels
- Each pair of outputs may be combined to produce 300w
- 1x balanced microphone input on euroblock connector
- 3x balanced line intputs on euroblock connectors
- 2x unbalanced stereo audio inputs summed to mono on RCA sockets
- 1x RJ45 port for CC-1, CC-2, CC-3 analog zone controllers
- Integrated webserver configuration utility facilitates setup of matrix mixer & Bose loudspeaker EQs
- Browser UI provides real-time controls including Vpeak/Vrms limiters, level, delays, SmartBass processing & signal monitoring on each channel
- Individually selectable 4/8Ω or 70/100v outputs
- Dimensions WxHxD 483x44x414mm
- Weight 6.6kg
data sheet
user manual
website
price inc gst $A 3520.00
Bose F1-812 Flexible Array Loudspeaker
- 12" LF driver with 8x 2¼" HF drivers in vertical array
- 2ch input with volume control
- Frequency response 52Hz~15.5kHz ±3db
- Dispersion 100°x40°
- Peak SPL 132db/1m
- Biamp 1000w
- Integral limiter
- Weight 20.2kg
- 2x 10" LF drivers
- Stereo crossover 100Hz with XLR HPF/thru outputs
- Subsonic filter 40Hz
- Frequency response 40~100Hz ±3db
- Integral limiter
- Maximum peak SPL 130dB/1m
- Amplifier power 2x500w
- Dimensions WxHxD 411x688x449mm
- Weight 24.9kg
F1-812 data sheet
F1-SUB data sheet
user manual
video clip
website
price inc gst $A 3395.00
BOSE ESP-880A8x8 Audio Processor
- 8x balanced mic/line inputs and 8x balanced analog line level outputs
- GPIO interface provides 5x control inputs and outputs for interface with Bose CC-4, DXA-VCW and DXA-VCS wall controllers
- RJ-45 ethernet port supports up to 16x CC-64 wall controllers via unshielded CAT5 cable and 10Base-T Ethernet hub
- RS-485 port on 3-pin phoenix connecter supports up to 15x CC-16 wall controllers
- Bose ESPLink provides 8x channels of uncompressed digital audio to ESPLink-equipped Bose PowerMatch® amplifiers
- Front panel RJ-45 ethernet connector enables configuration and control with ControlSpace® Designer™ software
- Dimensions WxHxD 483x44x215mm
- Weight 2.6kg
data sheet
website
user manual
software manual
price inc gst $A 2915.00
Bose L1 PRO16
Biamp Array Loudspeaker
Biamp Array Loudspeaker
- 16x 2" neodymium drivers in J-curve line array
- Bass module with 10x18" neodymium oval LF driver
- Power capacity HF 250w & LF 1000w
- LF frequency response 42Hz
- Dispersion 180°H;x-30°V
- Maximum SPL continuous 118db@1m peak 124db@1m
- 2ch input with independent volume control
- Digital ethercon port for T4S or T8S ToneMatch audio engines
- Dimensions WxHxD 355x2012x456mm
- Weight 24.8kg
data sheet
user manual
video clip
website
price inc gst $A 2412.00
Bose L1 PRO32
Line Array Loudspeaker
Line Array Loudspeaker
- 32x 2" neodymium drivers in straight line array
- Power capacity 480w
- Dispersion 180°H;x0°V
- Bluetooth connectivity
- 2ch input with independent volume control
- Digital ethercon port for T4S or T8S ToneMatch audio engines
- Column & stand dimensions WxHxD 345x2135x550mm
- Weight 13.0kg
data sheet
user manual
video clip
website
price inc gst $A 2159.00
Bose F1 SUB
Powered Bass Loudspeaker
Powered Bass Loudspeaker
- 2x 10" LF drivers
- Frequency response 40~100Hz ±3db
- Maximum peak SPL 130dB/1m
- Amplifier power 2x 500w
- Stereo crossover 100Hz with XLR HPF/thru outputs
- Subsonic filter 40Hz
- Integral limiter
- Dimensions WxHxD 411x688x449mm
- Weight 24.9kg
data sheet
user manual
video clip
website
price inc gst $A 1950.00
Bose SUB2
Powered Bass Loudspeaker
Powered Bass Loudspeaker
- 1x 10"x18" neodymium oval driver
- Power capacity 1000w
- LF frequency response 37Hz
- Threaded M20 socket for pole mount
- Dimensions WxHxD 305x690x550mm
- Weight 23.4kg
data sheet
user manual
video clip
website
price inc gst $A 1819.00
BOSE CSP-4284x10 Zone Controller
- 2x balanced mic-line inputs and 2x stereo line inputs summed to mono
- 2x balanced analog outputs and 8x digital AmpLink outputs
- Adjustable output levelling software
- Built in server for setup configuration with web browser
- Ethernet connection for control by optional ControlSpace Remote clients and BOSE CC-2D wallmount volume control & source selector
- Dimensions WxHxD 483x44x215mm
- Weight 2.6kg
website
data sheet
user manual
price inc gst $A 1806.00
Bose L1 PRO8
Biamp Array Loudspeaker
Biamp Array Loudspeaker
- 8x 2" neodymium drivers in C-curve line array
- Bass module with 7x13" neodymium oval LF driver
- Power capacity HF 60w & LF 240w
- LF frequency response 45Hz
- Dispersion 180°H;x±20°V
- Maximum SPL continuous 112db@1m peak 118db@1m
- 3ch input with independent volume controls
- Digital ethercon port for T4S or T8S ToneMatch audio engines
- Dimensions WxHxD 318x2005x440mm
- Weight 18kg
data sheet
user manual
video clip
website
price inc gst $A 1765.00
BOSE DM6SEBCoaxial Loudspeaker (pr)
- 165mm LF driver & 32mm dome HF driver
- Frequency response 70Hz~20kHz ±3db
- Dispersion 1~4kHz 125° conical
- Sensitivity 90db/1w@1m
- Power capacity 125w continuous 500w peak
- Maximum SPL @1m 110db average 116db peak
- Weatherproof rating IP55
- Included mounting bracket
- Dimensions WxHxD 340x222x229mm
- Dimensions with bracket WxHxD 340x222x245mm
- Weight with bracket 6.4kg
data sheet
user manual
website
price inc gst $A 1765.00
BOSE DM6SEWCoaxial Loudspeaker (pr)
- 165mm LF driver & 32mm dome HF driver
- Frequency response 70Hz~20kHz ±3db
- Dispersion 1~4kHz 125° conical
- Sensitivity 90db/1w@1m
- Power capacity 125w continuous 500w peak
- Maximum SPL @1m 110db average 116db peak
- Weatherproof rating IP55
- Included mounting bracket
- Dimensions WxHxD 222x340x229mm
- Dimensions with bracket WxHxD 222x340x245mm
- Weight with bracket 6.4kg
data sheet
user manual
website
price inc gst $A 1760.00
Bose F1 Model 812
Flexible Array Biamp Loudspeaker
Flexible Array Biamp Loudspeaker
- 1x Mic/line and 1x line inputs with volume controls
- 12" LF driver with 8x 2¼" HF drivers
- Frequency response 52Hz~16kHz ±3db
- Dispersion 100°x40°
- Peak SPL 132db/1m
- Biamplifier power 1000w
- Integral limiter
- Optional RMUBRKT1 pan & tilt wall bracket
- Dimensions WxHxD 335x665x373mm
- Weight 20.2kg
data sheet
user manual
video clip
website
price inc gst $A 1729.00
Bose MA12EX-BLine Array Loudspeaker
- 12x2¼" drivers in line array
- Frequency response 75Hz~13kHz ±3db
- Dispersion 160°x20°
- Sensitivity 87db@1m @1w/1m
- Maximum SPL 109db@1m RMS 115db@1m peak
- Power capacity 150w RMS 600w peak
- Dimensions WxHxD 104x985x139mm
- Weight 10kg
data sheet
user manual
price inc gst $A 1729.00
Bose MA12EX-WLine Array Loudspeaker
- 12x2¼" drivers in line array
- Frequency response 75Hz~13kHz ±3db
- Dispersion 160°x20°
- Sensitivity 87db@1m @1w/1m
- Maximum SPL 109db@1m RMS 115db@1m peak
- Power capacity 150w RMS 600w peak
- Dimensions WxHxD 104x985x139mm
- Weight 10kg
data sheet
user manual
price inc gst $A 1725.00
BOSE AMU108BIndoor-Outdoor Loudspeaker
- 8" LF driver & 1" EMB2S HF compression driver
- Frequency response 90Hz~16kHz ±3db
- Dispersion 100°x100°
- Sensitivity 91db @1w/1m
- Long term power capacity 200w
- Maximum SPL 119db@1m
- Outdoor rating IP55
- Included U-bracket
- Dimensions WxHxD 498x235x316mm with U-bracket
- Weight 12.6kg with U-bracket
data sheet
user manual
price inc gst $A 1725.00
BOSE AMU108WIndoor-Outdoor Loudspeaker
- 8" LF driver & 1" EMB2S HF compression driver
- Frequency response 90Hz~16kHz ±3db
- Dispersion 100°x100°
- Sensitivity 91db@1w/1m
- Long term power capacity 200w
- Maximum SPL 119db@1m
- Outdoor rating IP55
- Included U-bracket
- Dimensions WxHxD 498x235x316mm with U-bracket
- Weight 12.6kg with U-bracket
data sheet
user manual
price inc gst $A 1509.00
Bose T8S ToneMatch® Audio Engine
Digital Mixing Console
Digital Mixing Console
- 8x mic/line inputs on XLR-TRS-TS combo connectors with 48V phantom power
- 2x line inputs on ¼" TRS-TS connectors
- 1x USB port for streaming 2ch audio in/out
- 1x mono master output on ¼" TRS-TS connector
- 2x ToneMatch® ports on RJ45 connectors
- 1x pre-EQ or post-fade auxiliary send on ¼" TRS-TS connector
- Processing includes compressor, limiter, de-esser, noise gate, chorus, flanger, phaser, tremolo, delay and reverb
- Dimensions WxHxD 184x83x214mm
- Weight 1kg
data sheet
user manual
video clip
website
price inc gst $A 1495.00
BOSE IZA 2120HZMixer Amplifier
- 2-zone independent outputs with volume/source selection remotes, EQ, tone controls & paging/auxiliary routing options
- 1 balanced paging mic input on 4-pin euroblock connector
- 1 stereo line input mixed to mono, on ⅛" minijack connector
- 1 stereo line input mixed to mono, on RCA connectors
- 1 stereo line input mixed to mono, on 5-pin euroblock connector
- Power output 2x120w at 70V/100V
- Dimensions WxHxD 482x44x324mm
- Weight 4.1kg
data sheet
user manual
website
price inc gst $A 1429.00
Bose DM6EPWPendant Loudspeaker
- 150mm full range driver
- 25mm coaxial neodymium HF driver
- Frequency response 75Hz~20kHz ±3db
- Horizontal dispersion 115° conical @1~4kHz
- Sensitivity 89db/w/m @100Hz~10kHz
- Power capacity 100w continuous 400w peak
- Maximum SPL 109db/w/m continuous 116db/w/m peak
- Switchable 8Ω 70V & 100V
- Dimensions WxDxH 308Øx375mm
- Weight (ea) 5.7kg
data sheet
user manual
website
price inc gst $A 1409.00
Bose SUB1
Powered Bass Loudspeaker
Powered Bass Loudspeaker
- 1x 7"x13" neodymium oval driver
- Power capacity 480w
- LF frequency response 40Hz
- Threaded M20 socket for pole mount
- Dimensions WxHxD 250x530x530mm
- Weight 16.1kg
data sheet
user manual
video clip
website
price inc gst $A 1379.00
BOSE IZA 2120LZMixer Amplifier
- 2-zone independent outputs with volume/source selection remotes, EQ, tone controls & paging/auxiliary routing options
- 1 balanced paging mic input on 4-pin euroblock connector
- 1 stereo line input mixed to mono, on ⅛" minijack connector
- 1 stereo line input mixed to mono, on RCA connectors
- 1 stereo line input mixed to mono, on 5-pin euroblock connector
- Power output 2x120w at 4Ω
- Dimensions WxHxD 482x44x324mm
- Weight 4.1kg
data sheet
user manual
website
price inc gst $A 1325.00
BOSE DM6CWCoaxial Ceiling Loudspeaker (pr)
- 6½" cone LF driver
- 1¼" neodymium dome HF driver coaxially mounted
- Frequency response 70Hz~20kHz ±3db
- Dispersion 1~4kHz 120° conical
- Sensitivity 88db/1w@1m
- Power capacity 100w long term 400w peak
- Maximum SPL @1m 108db average 114db peak
- 80w transformer with front baffle tap selector
- Dimensions WxHxD 239Øx356mm
- Weight 6.5kg
data sheet
user manual
website
price inc gst $A 1315.00
BOSE CC64Wallmount Control for ControlSpace® systems
- Features bitmap LCD and four buttons for displaying and controlling system settings
- Up to sixteen CC-64s may be daisy-chained with unshielded CAT5 cable and 10Base-T Ethernet hub
- Requires Bose CC-PS1 universal power supply which may be connected either as POE or separate cable
user manual
price inc gst $A 1179.00
BOSE EM180Directional Loudspeaker
- 8" cone LF driver
- 1" compression mounted to PhaseGuide® device
- Frequency response 50Hz~18kHz ±3db
- Dispersion 1~4kHz 180Hx62V° -6db
- Sensitivity 93db/1w@1m
- Power capacity 125w long term 500w peak
- Maximum SPL @1m 114db average 120db peak
- 80w transformer with front baffle tap selector
- Dimensions WxHxD 390x250x390mm
- Weight 10.1kg
data sheet
user manual
website
price inc gst $A 1179.00
BOSE EM90Directional Loudspeaker
- 8" cone LF driver
- 1" compression mounted to PhaseGuide® device
- Frequency response 80Hz~18kHz ±3db
- Dispersion 1~4kHz 120° @-6db
- Sensitivity 96db/1w@1m
- Power capacity 125w long term 500w peak
- Maximum SPL @1m 117db average 123db peak
- 80w transformer with front baffle tap selector
- Dimensions WxHxD 390x250x390mm
- Weight 10.1kg
data sheet
user manual
website
price inc gst $A 1144.00
Bose MB 210BBass Loudspeaker
- 2x 10" LF drivers
- Frequency response 45~180Hz ±3db
- Sensitivity SPL 90dB/1m
- Maximum SPL 117dB/1m RMS 123dB/1m peak
- Power capacity 500w RMS 2000w peak
- Included U-bracket
- Dimensions WxHxD 685x291x418mm
- Weight 18.6kg
data sheet
user manual
website
price inc gst $A 1088.00
Bose L1 Compact
Powered Loudspeaker System
Powered Loudspeaker System
- 6x 2¼" drivers in line array
- Bass module with 8" LF driver
- Frequency response 65Hz~14kHz ±3db
- Dispersion 180°x40°
- Maximum SPL 106db@1m RMS 112db@1m peak
- 4ch input with 2 independent volume controls
- Amplifier power 130w
- Integral limiter
- Dimensions Compact WxHxD 339x418x426mm
- Dimensions Extended WxHxD 339x1995x426mm
- Weight 12.3kg
data sheet
user manual
video clip
price inc gst $A 1088.00
Bose L1 Compact
Powered Loudspeaker System
Powered Loudspeaker System
- 6x 2¼" drivers in line array
- Bass module with 8" LF driver
- Frequency response 65Hz~14kHz ±3db
- Dispersion 180°x40°
- Maximum SPL 106db@1m RMS 112db@1m peak
- 4ch input with 2 independent volume controls
- Amplifier power 130w
- Integral limiter
- Dimensions Compact WxHxD 339x418x426mm
- Dimensions Extended HxWxD 339x1995x426mm
- Weight 13.3kg
data sheet
user manual
video clip
price inc gst $A 1079.00
Bose T4S ToneMatch® Audio Engine
Digital Mixing Console
Digital Mixing Console
- 3x mic/line inputs on XLR-TRS-TS combo connectors with 48V phantom power
- 2x line inputs on ¼" TRS-TS connectors
- 2x USB port for streaming 2ch audio in+out
- 1x mono master output on ¼" TRS-TS connector
- 2x ToneMatch® ports on RJ45 connectors
- 2x pre-EQ or post-fade auxiliary send on ¼" TRS-TS connectors
- Processing includes compressor, limiter, de-esser, noise gate, chorus, flanger, phaser, tremolo, delay and reverb
- Dimensions WxHxD 184x83x214mm
- Weight 1kg
data sheet
user manual
video clip
website
price inc gst $A 1049.00
BOSE DM8SWCoaxial Loudspeaker
- 200mm LF driver & 25mm HF compression driver
- Frequency response 60Hz~20kHz ±3db
- Dispersion 1~3kHz 130° conical
- Sensitivity 93db/1w@1m
- Power capacity 150w long term 600w peak
- Maximum SPL @1m 114db average 120db peak
- Optional RMUBRKT1 pan & tilt wall bracket
- Included yoke bracket
- Dimensions WxHxD 249x395x253mm
- Dimensions with bracket WxHxD 249x395x270mm
- Weight with bracket 10.34kg
data sheet
user manual
website
price inc gst $A 999.00
Bose DM5SEWLoudspeaker (pr)
- 133mm full range driver
- 25mm coaxial neodymium HF driver
- Dispersion 135° conical @1~4kHz
- Frequency response 73Hz~17kHz ±3db
- Sensitivity 89db/w/m
- Power capacity 60w continuous
- Maximum SPL @1m 107db continuous 113db peak
- Environmental rating IP55
- Switchable 8Ω 70V & 100V
- Dimensions WxHxD 192x286x215mm
- Weight 4.38kg
data sheet
user manual
website
price inc gst $A 979.00
Bose DM5PWPendant Loudspeaker
- 133mm full range driver
- 25mm coaxial neodymium HF driver
- Frequency response 80Hz~20kHz ±3db
- Horizontal dispersion 120° conical @1~4kHz
- Sensitivity 87db/w/m @100Hz~10kHz
- Power capacity 50w continuous 200w peak
- Maximum SPL 104db/w/m continuous 110db/w/m peak
- Switchable 8Ω 70V & 100V
- Dimensions WxDxH 259Øx300mm
- Weight (ea) 4.1kg
data sheet
user manual
website
price inc gst $A 969.00
BOSE FS4SEBLoudspeaker (pr)
- 4½" cone full-range driver
- Frequency response 70Hz~17kHz ±3db
- Dispersion 1~4kHz 120° conical
- Sensitivity 89db/1w@1m
- Power capacity 50w long term 200w peak
- Maximum SPL @1m 105db average 111db peak
- 40w transformer with front baffle tap selector
- Weatherproof rating IP55
- Included mounting bracket
- Dimensions WxHxD 270x171x174mm
- Dimensions with bracket WxHxD 277x171x196mm
- Weight with bracket 3.42kg
data sheet
user manual
website
price inc gst $A 913.00
Bose DM5CWLoudspeaker
- 5¼" cone LF driver
- 1" neodymium dome HF driver coaxially mounted
- Dispersion 130° conical @1~4kHz
- Frequency response 73Hz~17kHz ±3db
- Sensitivity 87db/w/m
- Power capacity 50w continuous 200w peak
- Maximum SPL @1m 104db continuous 110db peak
- Environmental rating IP55
- Impedance switchable 8Ω 70V & 100V
- Dimensions WxHxD 303Øx205mm
- Weight 4.45kg
data sheet
user manual
website
price inc gst $A 899.00
BOSE FS4SEWLoudspeaker (pr)
- 4½" cone full-range driver
- Frequency response 70Hz~17kHz ±3db
- Dispersion 1~4kHz 120° conical
- Sensitivity 89db/1w@1m
- Power capacity 50w long term 200w peak
- Maximum SPL @1m 105db average 111db peak
- 40w transformer with front baffle tap selector
- Weatherproof rating IP55
- Included mounting bracket
- Dimensions WxHxD 171x270x174mm
- Dimensions with bracket WxHxD 171x277x196mm
- Weight with bracket 3.42kg
data sheet
user manual
website
price inc gst $A 880.00
BOSE DM8SBCoaxial Loudspeaker
- 200mm LF driver & 25mm HF compression driver
- Frequency response 60Hz~20kHz ±3db
- Dispersion 1~3kHz 130° conical
- Sensitivity 93db/1w@1m
- Power capacity 150w long term 600w peak
- Maximum SPL @1m 114db average 120db peak
- Optional RMUBRKT1 pan & tilt wall bracket
- Included yoke bracket
- Dimensions WxHxD 395x249x253mm
- Dimensions with bracket WxHxD 395x249x270mm
- Weight with bracket 10.34kg
data sheet
user manual
website
price inc gst $A 869.00
Bose S1 PRO
Battery Powered Loudspeaker System
Battery Powered Loudspeaker System
- 1x 6" LF driver, 3x 2" drivers in line array
- Frequency response 70Hz~16kHz ±3db
- Dispersion 100°x40°
- Maximum SPL RMS 103db@1m peak 109db@1m
- 2ch Tonematch mixer with volume, reverb, bass & treble control
- 1x stereo line input with independent volume control
- Bluetooth streaming on 3rd input
- Included Lithium-ion rechargeable battery
- Dimensions WxHxD 241x330x286mm
- Weight with battery 7.1kg
data sheet
user manual
video clip
website
price inc gst $A 847.00
BOSE DM8CWCoaxial Ceiling Loudspeaker
- 8" cone LF driver
- 1" compression driver coaxially mounted
- Frequency response 60Hz~20kHz ±3db
- Dispersion 1~4kHz 135° conical
- Sensitivity 91db/1w@1m
- Power capacity 125w long term 500w peak
- Maximum SPL @1m 112db average 118db peak
- 80w transformer with front baffle tap selector
- Dimensions WxHxD 255Ø x409mm
- Weight 9.6kg
data sheet
user manual
website
price inc gst $A 809.00
BOSE IZA 190HZMixer Amplifier
- 1 balanced XLR mic input
- 1 balanced paging mic input
- 2 stereo line inputs on RCA sockets
- Power output 90w at 100V
- Dimensions WxHxD 214x45x311mm
- Weight 3.2kg
data sheet
user manual
website
price inc gst $A 699.00
BOSE Freespace 3 BBRBass Loudspeaker Black
- 5¼" bass driver
- Frequency response 50Hz~230Hz
- Sensitivity 76db@1w/1m
- Power capacity 100w continuous 400w peak
- Maximum SPL 102db@1m continuous 108db@1m peak
- Wall mount bracket included
- Dimensions 356x191x345mm
- Weight 7.9kg
