• 24 microphone inputs
• 26dB pad, 80Hz high pass filters & switchable 48v phantom power
• One-knob compressor on all mono channels
• Direct outs on all mono channel
• 4-band EQ 2x mid-sweep & EQ in/out
• 8x group buses
• 8x aux sends pre/post
• 11x4 matrix mix
• 4x mute groups
• USB in/out and Cubase AI4 music software
• Included Yamaha PW8 power supply unit
• Dimensions WxHxD 1227x219x739mm
• Weight 37.5kg

• Meter bridge for Yamaha 02R & Yamaha 02RV2 mixing console
• LED bar meters display peak signal levels for all inputs, outputs and buses

• Analog interface for Yamaha 02R &Yamaha 03D digital consoles
• 8x ¼" balanced inputs on TRS jack sockets
• 8x ¼" balanced outputs on TRS jack sockets
• 20bit A/D and D/A converters
• On-board -10dbV +4dbV level switches for each connector
• Dimensions WxHxD 132x79x350mm
• Weight 1.15kg

• Interface for Yamaha 02R & Yamaha 03D digital consoles
• 8x channels AES/EBU format digital inputs on XLR connectors
• 8x channels AES/EBU format digital outputs on XLR connectors
• Sampling rates 44.1kHz & 48kHz

• Interface for Yamaha 02R & Yamaha 03D digital consoles
• 8x channels AES/EBU digital format inputs and outputs on 25-pin D-sub connector
• Sampling rates 44.1kHz & 48kHz

• Interface for Yamaha 02R & Yamaha 03D digital consoles
• 8x ADAT digital inputs and outputs on optical Toslink connectors

• 8 x TDIF format inputs and outputs on 25-pin D-sub connector with 24-bit A/D
• Sampling rate 44.1kHz & 48kHz
• Interface for DM1000, 01V, PM1D, DME32, AW4416, AW2816, SREV1, DM2000 and 02R96
• Yamaha MY Compatibility Chart

• Hard disk drive for Yamaha AW4416 digital recorder mounted with Yamaha ADP25H SCSI interface caddy
• Dimensions WxHxD 484x102x413mm
• Weight 6.4kg

• Interface for Yamaha DM1000, 01V, PM1D, DME32, AW4416, AW2816, SREV1, DM2000 and 02R96
• 8x ADAT format inputs and outputs on 2 TOS-Link connectors with 24-bit A/D
• Sampling rate 44.1kHz & 48kHz
• Yamaha MY Compatibility Chart

• Frequency response 30Hz~4000Hz
• Sensitivity 102dB @1w/1m
• Power capacity RMS 150w continuous 300w
• Dimensions 390Ø x148mm
• Net weight 11.6kg

Yamaha NB 087560

Recone Kit for JA3806 Driver

• 15" cone 2" voicecoil for JA3806 driver

• SCSI interface caddy for mounting Yamaha CRW8824S hard disk drive into Yamaha AW4416 digital recorder

• Horn loaded driver
• Frequency response 3kHz~20kHz
• Crossover frequency 3kHz
• Designed for Yamaha S2108H, MS60S & S3110T loudspeaker systems

Yamaha BMS-10A

Microphone Stand Adaptor

• Designed to mount:
  • MSP3 loudspeakerS15 loudspeaker
  • MG8/2FX mixerSTAGEPAS150M mixer
• Load capacity 5kg

• 12x analog inputs with 48v phantom power on 12 channels
• 2x internal stereo multi-effects processors
• 22x dynamics processors
• 99 programmable "snapshot" memories
• Optional mini-YGDAI cards
  • Yamaha MY8-AT 8ch ADAT input/output card
  • Yamaha MY8-TD 8ch TASCAM input/output card
• Dimensions WxHxD 430x148x520mm
• Weight 12.5kg

• 24-bit 96-kHz resolution with optional 44.1/48/88.2 modes
• 12 high-performance microphone inputs
• 4 balanced/unbalanced line inputs may be used as 2 stereo pairs
• 8 digital channel inputs via built-in ADAT optical interface
• Input channel includes 4-band parametric EQ, dynamics & delay to 452ms
• 2 built-in effects with 96-kHz resolution
• 20 mix busses, stereo program, eight sub-groups, eight auxiliaries & two solo buses
• Optional mini-YGDAI cards
  • Yamaha MY8-AT 8ch ADAT input/output card
  • Yamaha MY8-TD 8ch TASCAM input/output card
• Dimensions WxHxD 436x150x540mm
• Weight 15kg

• 28 channel digital mixing with DAW remote control by motorized faders
• 2x Balanced mic/line inputs on XLR sockets
• 6x Balanced mic/line inputs on ¼" TRS sockets
• 24-bit/96kHz low latency multi-channel audio interface over mLAN for both Windows and Mac
• Dimensions WxHxD 391x116x391mm
• Weight 6.2kg

• 16x fader 8-bus console for recording, post-production & live performance
• 4-way PEQ & dynamics processor on every input channel and output bus
• 2x internal stereo multi-effects processors
• Bus outputs, aux sends, channel direct outs, and stereo output may be assigned to CD8 interface cards
• 32-bit internal digital processing
• Optional Yamaha MB02 meter bridge
• Optional YGDAI cards
  • Yamaha CD8-AD 8ch analog input card
  • Yamaha CD8-AES 8ch AES/EBU input/output card
  • Yamaha CD8-AT 8ch ADAT input/output card
  • Yamaha CD8-TD 8ch TASCAM input/output card
  • Yamaha CD8-AE 8ch AES/EBU input/output card
• Dimensions 663x685x222mm
• Weight 30kg

Yamaha 02R96 V2

Digital Production Console

• 24-bit 96-kHz resolution with 32-bit internal processing and 58-bit accumulators
• All 56 input channels feature compression and gating/ducking processors for dynamics control
• 4-band parameter channel equalizers also offer extra versatility with switchable "type I" or "type II" EQ algorithms
• Channel delay with a maximum delay of 453 milliseconds
• 5.1 surround processing, panning, monitoring and joystick
• Flexible bus system with digital patching inserts
• Dimensions WxHxD 667x239x697mm
• Weight 34kg

Yamaha 02R96 VCM

Digital Production Console

• 24-bit 96-kHz resolution with 32-bit internal processing and 58-bit accumulators
• All 56 input channels feature compression and gating/ducking processors for dynamics control
• 4-band parameter channel equalizers also offer extra versatility with switchable "type I" or "type II" EQ algorithms
• Channel delay with a maximum delay of 453 milliseconds
• 5.1 surround processing, panning, monitoring and joystick
• Flexible bus system with digital patching inserts
• Dimensions WxHxD 667x239x697mm
• Weight 34kg

• 16x fader 8-bus console for recording, post-production & live performance
• 4-way PEQ & dynamics processor on every input channel and output bus
• 2x internal stereo multi-effects processors
• Bus outputs, aux sends, channel direct outs, and stereo output may be assigned to CD8 interface cards
• 32-bit internal digital processing
• Optional Yamaha MB02 meter bridge
• Optional YGDAI cards
  • Yamaha CD8-AD 8ch analog input card
  • Yamaha CD8-AES 8ch AES/EBU input/output card
  • Yamaha CD8-AT 8ch ADAT input/output card
  • Yamaha CD8-TD 8ch TASCAM input/output card
  • Yamaha CD8-AE 8ch AES/EBU input/output card
• Dimensions 663x685x222mm
• Weight 30kg

• 16-fader, 26-input 18-output digital mixing console
• 8 microphone inputs with 48V phantom power
• 4-bus, 4-aux, stereo & monitor anallog outputs
• 2 internal stereo 32-bit multi-effects processors with
• Fully-automated with instant recall of 50 pre-programmed "snapshot" memories
• Optional YGDAI cards:
  • Yamaha CD8-AD 8ch analog input card
  • Yamaha CD8-AT 8ch ADAT input/output card
  • Yamaha CD8-TD 8ch TASCAM input/output card
  • Yamaha CD8-AE 8ch AES/EBU input/output card
  • Yamaha CD8-AES 8ch AES/EBU input/output card
  • Yamaha CD8-CS-KIT card & cable kit to digitally connect Yamaha 02R and  Yamaha 03D
• Dimensions WxHxD 460x204x516mm
• Weight 16kg

• 10" LF driver
• 1" titanium HF compression driver
• Frequency response 65Hz~20kHz
• Sensitivity 97dB 1w/1m
• Power capacity 300w continuous 600w peak
• Dimensions WxHxD 385x535x307mm
• Weight 14.4kg

• 12" LF driver
• 1" titanium HF compression driver
• Frequency response 65Hz~20kHz
• Sensitivity 97dB 1w/1m
• Power capacity 300w continuous 600w peak
• Dimensions WxHxD 405x575x323mm
• Weight 16kg

• 12" LF driver
• 1" titanium HF compression driver
• Frequency response 65Hz~20kHz
• Sensitivity 97dB 1w/1m
• Power capacity 300w continuous 600w peak
• Dimensions WxHxD 575x405x323mm
• Weight 15.6kg

• 15" LF driver
• 1" titanium HF compression driver
• Frequency response 65Hz~20kHz
• Sensitivity 98dB 1w/1m
• Power capacity 400w continuous 800w peak
• Dimensions WxHxD 470x665x375mm
• Weight 21.3kg

• 15" LF driver
• Frequency response 50Hz~200Hz
• Sensitivity 97dB 1w/1m
• Power capacity 500w continuous 1000w peak
• Dimensions WxHxD 485x622x485mm
• Weight 20.9kg

• 1.4" diameter throat driver to 2" diameter horn entry
• Designed for Yamaha AD3550 driver
• Dimensions 128Ø x63mm

• 24bit 44.1kHz & 48kHz A/D converter
• 8 balanced XLR input connectors
• 8 balanced insert on ¼" TRS connectors
• Word clock input and thru
• Mini-YGDAI card slot (ADAT, TASCAM, AES/EBU) allow operation as stand-alone converters

• 8 mic/line inputs on XLR connectors
• 48v phantom power
• 8 remotely controllable head amps
• 24-bit/96-kHz AD Converter
• 9p D-sub head amp remote connector
• 9p D-sub RS-422 connector
• 2 D-sub 25p AES-EBU input/output connector
• BNC wordclock input & output

• 8 XLR/TRS microphone/line inputs with switchable phantom power
• 4-band EQ, compression and gating on all mixer channels
• 2 assignable digital effect processors
• Builtin CD-RW drive lets you burn CD audio masters and data backups

• 16 XLR/TRS microphone/line inputs with switchable phantom power
• 4-band EQ, compression and gating on all mixer channels
• 2 assignable digital effect processors
• Built-in CDRW drive lets you burn CD audio masters and data backups

• 28 input channels, 18 mix buses
• Dynamics processing on all input channels and main stereo bus
• 2 powerful onboard effect processors
• CD mastering without ever leaving the digital domain
• AW2816.com Pro-User Site

• 44x input channels
• 20x mix buses
• Dynamics processing on all input channels and main stereo bus
• 2x effect processors
• CD mastering to onboard CDR recorder
• Dimensions WxHxD 558x148x460mm
• Weight 11.8kg

• Power capacity 2x 100w@8Ω
• ToP-ART® Total Purity Audio Reproduction Technology
• 5x Stereo line inputs on stereo RCA sockets
• CD/DVD direct amplification
• Record/zone2 output selector
• Dimensions WxHxD 435x151x396mm
• Weight 10.6kg

• Designed to mount:
  • MS400 Loudspeaker
• For attachment to the following brackets:
  • BBS 251 Baton bracket
  • BCS 251 Ceiling bracket
  • BWS 251-400 Wall bracket
• Load capacity 40kg

• Designed to mount:
  • C112VA Loudspeaker
  • CBR10 Loudspeaker
  • CBR15 Loudspeaker
  • DBR10 Loudspeaker
  • DBR12 Loudspeaker
  • DBR15 Loudspeaker
  • HS7I Loudspeaker
  • IF2108 Loudspeaker
  • IF2205 Loudspeaker
  • IF2208 Loudspeaker
  • MSR100 Loudspeaker
  • MSR250 Loudspeaker
  • MSR400 Loudspeaker
• Designed to mount with BAD 251 Bracket adaptor:
  • MS400 Loudspeaker
• Load capacity 30kg
• Length 267mm
• Weight 2.3kg

• Ceiling mount bracket designed for loudspeaker S250X
• Load capacity 20kg

• Designed to mount:
  • C112VA Loudspeaker
  • CBR10 Loudspeaker
  • CBR15 Loudspeaker
  • DBR10 Loudspeaker
  • DBR12 Loudspeaker
  • DBR15 Loudspeaker
  • HS7I Loudspeaker
  • IF2108 Loudspeaker
  • IF2205 Loudspeaker
  • IF2208 Loudspeaker
  • MSR100 Loudspeaker
  • MSR250 Loudspeaker
  • MSR400 Loudspeaker
• Designed to mount with BAD 251 Bracket adaptor:
  • MS400 Loudspeaker
• Maximum tilt angle 45°
• Load capacity 30kg
• Weight 2.3kg

Yamaha BFS250

Loudspeaker Stand
^{loudspeaker shown for ilustration}

• Floor mount designed for loudspeaker S250X
• Load capacity 20kg

Yamaha BWS20-120

Loudspeaker Mount Bracket

• Wall or ceiling bracket designed to mount
  • HS7I loudspeaker
  • MSP7STUDIO loudspeaker
  • MSR-100 loudspeaker
• Load capacity 7kg
• Weight 1.4kg

Yamaha BWS20-190

Loudspeaker Wall Mount Bracket

• Designed to mount:
  • HS7I loudspeaker
  • MSP7STUDIO loudspeaker
  • MSR-100 loudspeaker
• Load capacity 7kg
• Weight 1.7kg

Yamaha BWS250

Loudspeaker Mounting Bracket
^{loudspeaker shown for ilustration}

• Wall mount bracket designed for loudspeaker S250X
• Load capacity 20kg

• Designed to mount:
  • C112VA Loudspeaker
  • CBR10 Loudspeaker
  • CBR15 Loudspeaker
  • DBR10 Loudspeaker
  • DBR12 Loudspeaker
  • DBR15 Loudspeaker
  • HS7I Loudspeaker
  • IF2108 Loudspeaker
  • IF2205 Loudspeaker
  • IF2208 Loudspeaker
  • MSR100 Loudspeaker
  • MSR250 Loudspeaker
  • MSR400 Loudspeaker
• Designed to mount with BAD 251 Bracket adaptor:
  • MS400 Loudspeaker
• Maximum tilt angle 45°
• Load capacity 30kg
• Weight 5.2kg

Yamaha BWS50-260

Loudspeaker Wall Mount Bracket

• Designed to mount:
  • HS7I  loudspeaker
  • MSP7STUDIO  loudspeaker
  • MSR-100  loudspeaker
• Maximum tilt angle 30°
• Load capacity 20kg
• Weight 1.4kg

• 12" LF driver
• 2" titanium HF compression driver
• Dispersion 90°x40°
• Frequency response 60Hz~16kHz @-10db
• Sensitivity 97dB 1w/1m
• Power capacity 175w rms 700w peak
• Maximum SPL 126dB/1m @ 10%THD
• Dimensions WxHxD 628x410x339mm
• Weight 21.8kg

Yamaha C112VA

* Shown with optional Yamaha BBS-251 bracket

• 12" LF driver
• 2" titanium HF compression driver
• Dispersion 90°x40°
• Frequency response 60Hz~16kHz @-10db
• Sensitivity 97dB 1w/1m
• Power capacity 175w rms 700w peak
• Maximum SPL 126dB/1m @ 10%THD
• 12x Integral flypoints
• Dimensions WxHxD 416x620x329mm
• Weight 21.8kg
